AluLITE Product Range

Monorail Sliding with Mesh, 3 Sliding Rails, 3 Sliding Rails with Fly Mesh Shutter

Frame and System

Opening Frame

Maximum Shutter Height 3050 mm
Maximum Shutter Size 5 sqm
Maximum Glass Infill 32 mm
Maximum Shutter Weight 180 kg

General

All sections are extruded from aluminium alloy specification 6060/6063 T6. Aluminium extrusions are optimally designed to meet various requirements of functionality and strength. A wide range of profiles, with different moments of inertia, ensure economic application for varied structural requirements.

System

Miter 45° and straight 90° cut rails and lateral frames. Opening frame standard or reinforced central mullion in accordance with the size of the frame and structure exposure. Sections with single glazing and double glazing groove.

Product Features

EURO design system assembled with accessories and hardware of anti-corrosive materials and special EPDM gaskets for special air and water tightness of the system.

Ergonomic design with flat profiles available in CLASSIC, miter cut 45 degrees (mullion face width of 36mm) and modern design, straight cut 90 degrees.

Modular system designed with no architectural barriers for optimization of spaces and maximum transparency.

Innovative MONORAIL system, a composite of fixed and sliding system that allows for a covered fixed outer frame profile and option of integrating retractable mesh against sliding shutter on inner track.

Outer frame tracks designed with CONDENSATION profile for collection and draining out of water through drainage slots (weep holes) in non-visible areas.

Smooth sliding movement due to INOX sliding tracks, shutters provided with self-adjusting double nylon or SS rollers and theft guards.

Multiple color options in handles and multipoint cylinder key locking operation.

Wrap around glazing gasket for best possible protection of glazing edges and minimal use of plastic parts for better aesthetics and maintenance.

Internal and external fly screen mesh solutions.

The design creates the exceptional, where science and art break even to create seamless boundaries, blurring the fine line between the indoors and the outdoors.

absolute-security
Absolute Security
eco-friendly
Environment Friendly
fire-proof
Fire Proof
high-quality-finish
High Quality Finish
long-lasting
Long Lasting
termite-proof
Termite Proof
value-for-money
Value for Money
weather-proof
Weather Proof
AluLITE

Product Finishes

Anodising

champagne
Champagne
black
Anodic Black

Sublimation

wenge
Wenge

Power Coating

white
White
warm-grey
Warm Grey
cold-grey
Cold Grey
anodic-bronze
Anodic Bronze
Matt Black
